RCX SE2205 2400KV Racing Motor (Japan EZO Bearing / N52H Arc Magnet) (Copy)

Description Specification: Model: SE2205 V2 KV: 2400KV Weight: Approx. 28.6g (net weight included long AWG cables) you can lower the weight if you shorten the long AWG cables. AWG Cable: 15cm (long enough) Prop Shaft Diameter: 5mm (CW) Stator Diameter: 22mm Stator Length: 5mm Shaft Diameter: 3mm Configuration: 12N14P Motor Dimensions: Φ26.8×15.3mm ldle Current: 0.00A @ 10V Internal Resistance: 0.00Ω Suitable ESC: 25-40A (depends on the propeller and battery you use) HobbyWing’s XRotor works pretty well with SE2205 V2 motor so it is recommended especially the XRotor 30A is small in size as small as some 10A-12A ESC. Since SimonK and BLHeli might shutter during high RPM on small props (eg. 5030). So if you plan to drive the motor hard, please consider to get XRotor 30 because XRotor was tested at high RPM without any sync issue. Suitable Battery: 3-4S Li-Po (refer to thrust test table and videos)   Includes: 1 x RCX SE2205 V2 2400KV FPV Racing Edition Motor 1 x Aluminium Locknuts M5 (Slip-Resistant) – CW 1 x Circle Plate 1 x Set of M3*5 Screw
