HHOBD ELM327 Bluetooth Vehicle diagnostic scanner

Description For your vehicle to be OBD II compliant it must have a 16-pin DLC (Data Link Connector) under the dash and the Vehicle Emission Control Information Label must state that the vehicle is OBD II compliant. This device is NOT compatible with Apple devices Note: Some Known cars that the scanners is not compatible are: VW Polos Fortuner Hilux Older Corsa Bantam Features: Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). Clear trouble codes and turn off the MIL (“Check Engine” light) Display current sensor data Engine RPM Calculated Load Value Coolant Temperature Fuel System Status Vehicle Speed Short Term Fuel Trim Long Term Fuel Trim Intake Manifold Pressure Timing Advance Intake Air Temperature Air Flow Rate Absolute Throttle Position Oxygen sensor voltages/associated short term fuel trims Fuel System status Fuel Pressure Functions: 1. Read diagnostic trouble codes, both generic and manufacturer-specific, and display their meaning (over 3000 generic code definitions in the database). 2. Clear trouble codes and turn off the MIL (“Check Engine” light) 3. Display current sensor data, including: 4. Engine RPM 5. Calculated Load Value 6. Coolant Temperature 7. Fuel System Status 8. Vehicle Speed 9. Short Term Fuel Trim 10. Long Term Fuel Trim 11. Intake Manifold Pressure 12. Timing Advance 13. Intake Air Temperature 14. Air Flow Rate 15. Absolute Throttle Position 16. Oxygen sensor voltages/associated short term fuel trims 17. Fuel System status 18. Fuel Pressure Does not support J1850 VPW and J1850 PWM protocol (The agreement used by some vehicles before 2007) ISO9141-2(5 baud init,10.4Kbaud) ISO14230-4 KWP(5 baud init,10.4 Kbaud) ISO14230-4 KWP(fast init,10.4 Kbaud) ISO15765-4 CAN(11bit ID,500 Kbaud) ISO15765-4 CAN(29bit ID,500 Kbaud) ISO15765-4 CAN(11bit ID,250 Kbaud) ISO15765-4 CAN(29bit ID,250 Kbaud) SAE J1939 CAN(29bit ID,250xKbaud) CAN(11xbit ID,125xKbaud) CAN(11xbit ID,50xKbaud) Support PC / Android phone (software not included) For Android user: Please download any ELM327 compatible app of your choice FAQ: How do I pair ELM327 Bluetooth OBD2 Car Diagnostic Interface Tool? 1. Make sure your car is OBD2 compatible. 2. Locate your car’s OBD II diagnostic port and plug in your scanner. It’s usually found under the driver’s side dashboard, under the steering wheel. 3. Turn on your ignition by turning your key to the 2nd turn. The engine will be off, but this provides power to your dash lights, radio and also the OBD II diagnostic port. 4. From your Android Smartphone or tablet, go to your SETTINGS, then WIRELESS & NETWORKS, then BLUETOOTH SETTINGS. Turn on Bluetooth, scan for the nearby devices and pair your phone with the scanner (Password 1234 or 0000). Bluetooth Pairing Issues: 1. Restart your phone 2. Unpair any existing Bluetooth diagnostic tools. 3. Make sure the diagnostic App is NOT running in the background. Close the app before pairing 4. If the password 1234 doesn’t work, try 12345 or 0000 5. Turn off Bluetooth, turn it back on and rescan for the device What’s in the box 1 x Bluetooth OBD2 Car Diagnostic Interface Tool
